SENSOR

1/2.5 inch 8MP CMOS sensor

HDMI

3840*2160p30/25; 1920*1080p60/59.94/50/30/29.97/25/24; 1920*1080i60/59.94/50; 1280*720p60/59.94/50/30/29.97/25

IP

Main streamㄩ3840*2160@15~30˙1920*1080@15~30˙

1280*720@15~30˙1024*576@15~30

Sub streamㄩ1280*720@15~30˙1024*576@15~30˙640*360@15~30

SDI

1920*1080p60/59.94/50/30/29.97/25/24, 1920*1080i60/59.94/50, 1280*720p60/59.94/50/30/29.97/25:

USB

USB3.0: 1920*1080p60/50/30/25, 1280*720p60/50/30/25, 1024*576p30

USB2.0: 1024*576p30,960*540p30,640*360p30, 512*288p30, 1280*720p25

IMAGEN

Zoom: 12x optical zoom+2x digital zoom

FOV: 6.3﹉ㄗTeleㄘ~72.5﹉ㄗFarㄘ

Iris No.: Wideㄩ1.84   Tele ㄩ2.81

Min Focus Distance: Wideㄩ0.3m   Teleㄩ1m

Noise Reduction: 2D&3D

S/N: >50dB

Focal Length: fˊ3.92(Wide)＃47.32mm(Tele)

Min LUX: 0.1 LUX

White Balance: Auto / Manual/Indoor/Outdoor/ATW/ONEPUSH/Sodium /Fluorescent

Focus: Auto/Manual

Iris: Auto/Manual

Shutter Speed: Auto/Manual

Backlight Compensation: Auto/Manual

Image Flip: Supported

Video Freeze: Optional

ENCODE

Video Encoding Standard: H.264/H.265

Network Speed: 1000M

Bit Rate Control: Variable Bit Rate, Constant Bit Rate

Video Bit Rate: 1024Kbps~51200Kbps

Frame Rate: 50HZ: 15fps~30fps  60HZ: 15fps~30fps  ㄗ3840*2160 max 30fpsㄘ

Protocol: NDI, TCP/IP, HTTP, RTSP, RTMP, ONVIF, DHCP, VISCA over IP (UDP&TCP), HTML5

MECANISMO

Pan Rotation Angel: Pan:  -170﹉ ~ +170﹉;          Tilt:  -30﹉ ~ +90﹉

Pan Rotation Speed: Pan: 0﹉~120﹉/s;            Tilt:  0﹉~80﹉/s

Preset: 128

Control Port: NDI|HX/RS232/RS485/USB3.0

Video Port: NDI|HX, 3G-SDI, HDMI, USB3.0

POE: Supported, POE+ (IEEE802.3at)

Voltage: DC12V

DimensionㄗW x H x Wㄘ: 220mm▼173mm▼117mm

Net Wight: 1.4KGㄗ3.1LBSㄘ
