Video Input Connectors | 1 x HDMI Female |
Input Video Format | HDMI (4:4:4/4:2:2 RGB, YUV) |
Audio Input Connectors | 1 x 1/8" / 3.5 mm TRS Stereo Analog Female |
Embedded Audio Input | SDI: 2-Channel (per Input) |
Video Output Connectors | 1 x HDMI Female |
Output Video Format | HDMI / SDI (4:4:4/4:2:2 RGB, YUV) |
Audio Output Connectors | None |
Embedded Audio Output | HDMI: 2-Channel (per Output) |
Video Standard Compliance | SMPTE 259M/292M/424M-B |
Other I/O | 1 x USB Micro-B Firmware, Control Input |
Expansion Slots | None |
Power Connector | 2 x Barrel Input |
Power Consumption | Device: 6 to 23 VDC (4 W) |
Operating Temperature | -4 to 140°F / -20 to 60°C |
Storage Temperature | -22 to 158°F / -30 to 70°C |
Operating Humidity | 0 to 90% |
Dimensions | 4.94 x 4.09 x 0.96" / 125.5 x 104 x 24.5 mm |
Weight | 17.11 oz / 485 g |
Warranty Length | Limited 3-Year Warranty |
